DJI O4 Air Unit Lite Camera and VTX

DJI O4 Air Unit (Lite) Digital FPV System

The DJI O4 Air Unit has arrived!

Designed for high-performance FPV, the DJI O4 Air Unit combines advanced DJI transmission technology with a compact, lightweight design. Delivering impressive image quality over long distances, it provides ultra-low latency for an immersive flying experience. Equipped with cutting-edge video processing and a 155° super-wide field of view, the O4 Air Unit offers exceptional clarity and responsiveness. Its versatile compatibility with a range of systems makes it an ideal choice for both hobbyists and professionals. Elevate your FPV experience with the DJI O4 Air Unit!

Specifications

Air Unit

• Weight
  • Air Unit (camera module excluded): 5.1 g
  • Air Unit (camera module included): 8.2 g
  • Antenna: 0.75 g
• Dimensions
  • Transmission Module: 30×30×6 mm
  • Camera Module: 13.44×12.36×16.50 mm
  • Coaxial Cable: 50 mm
  • 3-in-1 Cable: 50 mm
  • Antenna: 80 mm

Video Transmission

• Operating Frequency
  • 5.170-5.250 GHz
  • 5.725-5.850 GHz
• Transmitter Power (EIRP)
  • 5.1 GHz: <23 dBm
  • 5.8 GHz: <30 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
• Lowest Latency
  • With DJI Goggles 3: 20 ms
  • With DJI Goggles N3: 24 ms
  • With DJI Goggles 2/Goggles Integra: <35 ms
• Max Video Transmission Range
  • With DJI Goggles 3/DJI Goggles N3: 10 km (FCC), 6 km (CE/SRRC)
• Live View Quality: 1080p@30/50/60/100fps
• Communication Bandwidth: Max 60 MHz
• Antenna: 1T1R

Camera

• Image Sensor: 1/2-inch CMOS
• Lens
  • FOV: 117.6°
  • Equivalent Focal Length: 14 mm
  • Aperture: f/2.8
  • Focus: 0.6 m to ∞
• ISO Range: 100-6400 (Auto), 100-12800 (Manual)
• Video Resolution
  • 4K (4:3): 3840×2880@30/50/60fps
  • 4K (16:9): 3840×2160@30/50/60fps
  • 1080p (4:3): 1440×1080@30/50/60/100/120fps
  • 1080p (16:9): 1920×1080@30/50/60/100/120fps
• Video Format: MP4
• Max Video Bitrate: 100 Mbps
• Color Mode: Normal Mode
• EIS: RockSteady 3.0+

Hardware

• Input Voltage: 3.7-13.2 V
• Operating Temperature: -10° to 40° C
• Storage
  • Built-in Storage: 23 GB
  • SD Card Support: Not supported

Compatibility

• Supported Flight Controller: Betaflight 4.3.0 and above
• Supported DJI Goggles and Controllers
  • DJI Goggles 3 + DJI FPV Remote Controller 3
  • DJI Goggles N3 + DJI FPV Remote Controller 3
  • DJI Goggles 2/Goggles Integra + DJI FPV Remote Controller 2

Includes

• 1x DJI O4 Air Unit Camera Module
• 1x DJI O4 Air Unit Transmission Module
• 1x DJI O4 Air Unit Antenna
• 1x DJI O4 Air Unit 3-in-1 Cable
